NM500A IFM Inductive Sensor | Industrial Sensors – KMSPARE

IFM NM500A Inductive Sensor – Long Range & Intrinsically Safe

The IFM NM500A inductive sensor is expertly designed for industrial applications that demand high reliability and intrinsically safe operation. Featuring a sensing distance of 20 mm and robust PBT plastic housing, it is ideal for hazardous areas, material handling, and conveyor systems.

⚙️ Product Specifications:

• Brand: IFM

• Model Number: NM500A

• Sensor Type: Inductive

• Output Type: PNP

• Sensing Distance: 20 mm

• Voltage Range: 10 – 30 V DC

• Current Consumption: 5 mA

• Leakage Current Load: 30 mA

• Maximum Switching Current: 35 mA

• Response Frequency: 50 Hz

• Operating Frequency: 200 Hz

• Power Rating: 10 A

• Protection Class: IP65

• Material: PBT Plastic

• Color: Black, Blue

• Dimensions (W x H x L): 40 x 40 x 66 mm

• Weight: 181.5 g

✅ Key Features:

• Suitable for hazardous areas – NAMUR compliant

• Long sensing range for conveying and automation

• Durable and sealed housing for tough environments

• Flexible installation with five selectable sensing face positions

• Designed for use with intrinsically safe circuits

Model Code: NM500AIMC2020BN/US/2G/1D
📞 Contact us for pricing, availability, and technical support.
