IFM NN5013 Inductive Sensor – Dual Sensor Solution for Valve Actuators

The IFM NN5013 is a robust inductive NAMUR dual sensor designed specifically for monitoring valve positions in industrial automation. With a compact and durable design, this sensor offers reliable position feedback even in hazardous environments and can be quickly installed using just three screws.

⚙️ Technical Specifications:

• Brand: IFM

• Model Number: NN5013

• Sensor Type: Inductive NAMUR Dual Sensor

• Sensing Distance: 5 mm

• Output Type: PNP

• Switching Function: Normally Open (NO)

• Voltage Range: 18 – 35 V DC

• Current Consumption: 15 mA

• Leakage Current Load: 10 mA

• Max Switching Current: 30 mA

• Response Frequency: 50 / 60 Hz

• Operating Frequency: 50 / 60 Hz

• Body Material: PBT Plastic

• Protection Class: IP67

• Dimensions (W x H x L): 40 x 26 x 26 mm

• Color: Orange

• Power: 15 A

✅ Key Features:

• Designed for valve actuator monitoring

• Reliable feedback for valve position control in industrial setups

• Compatible with intrinsically safe circuits

• Fast installation with only three screws

• High protection rating (IP67) for harsh environments

• Dual-sensor configuration ensures precise, redundant sensing

Model Code: NN5013IND2004DN/BS-200-K/1D/1G/2G
📞 Contact us for pricing and availability.
