NN506A IFM Inductive Sensor | Industrial Sensors – KMSPARE

IFM NN506A Inductive Sensor – Reliable Valve Position Feedback for Industrial Use

The IFM NN506A inductive sensor is purpose-built for monitoring valve positions in industrial and hazardous areas. Its non-contact, self-cleaning system ensures dependable operation even in demanding environments, providing accurate and consistent feedback.

🔧 Technical Specifications:

• Brand: IFM

• Model Number: NN506A

• Sensor Type: Inductive

• Output Type: PNP

• Switching Function: Normally Open (NO)

• Sensing Distance: 5 mm

• Voltage Range: 10 – 30 V DC

• Current Consumption: 10 mA

• Leakage Current Load: 20 mA

• Maximum Switching Current: 35 mA

• Response Frequency: 50 Hz

• Operating Frequency: 60 Hz

• Power Rating: 10 A

• Protection Rating: IP67

• Body Material: PBT Plastic

• Color: Orange

• Dimensions (W x H x L): 33 x 60 x 119 mm

• Weight: 176.5 g

✅ Key Features:

• Designed for reliable position feedback on valve actuators

• Intrinsically safe circuit compatible for hazardous areas

• Non-contact and self-cleaning design for extended life

• High protection class (IP67) for harsh industrial environments

• Compact rectangular housing for space-efficient installations

Model Code: NN506AINE2004DN/1D/1G/2G
📦 Reach out to us for pricing, availability, or bulk orders.
