O1D155 IFM Photoelectric Distance Sensor

IFM Optical Distance Sensor | 40m Range | 2m Rated | High Accuracy | IP55

Enhance your industrial automation with the IFM Optical Distance Sensor, delivering precise distance measurement up to 40 meters and a rated detecting range of 2 meters. Designed for durability and performance, this sensor offers scalable measuring with both switching and analog outputs, perfect for demanding environments like automotive and manufacturing.

🔧 Technical Specifications:

• Brand: IFM

• Distance Range: Up to 40 m

• Rated Detecting Distance: 2 m

• Model Material: PBT

• Color: Black

• Supply Voltage: 10 – 30 V DC

• Supply Current: 15 mA

• Operating Temperature: -20°C to +55°C

• Max Working Temperature: 70°C

• Accuracy: 100%

• Protection Class: IP55

• Output Type: 2 switching outputs (1 programmable as analog)

• Laser Protection: Class 1

✅ Key Features:

• Reliable optical measurement with extended range (up to 40m)

• Scalable measuring range with window function

• Versatile output configuration (switching + analog)

• Laser Class 1 protection – safe for use in automotive environments

• Compact, PBT housing for rugged industrial use

• Excellent performance-to-price ratio

🏭 Applications:

• Automotive manufacturing and assembly lines

• Position and distance monitoring

• Object detection in conveyor systems

• Warehouse and logistics automation

Take precision to the next level with the IFM 40m Optical Distance Sensor — a reliable, efficient, and robust solution for a wide range of industrial applications.
