O2D224 IFM Object Recognition Sensor | Industrial Sensors – KMSPARE

Industrial Object Recognition Sensor | High-Precision Infrared CMOS | IP67 Rated

Maximize accuracy and efficiency in automated inspection and object recognition with this Industrial Proximity Sensor featuring a CMOS image sensor and infrared light source. Designed for reliable, high-speed recognition, it offers a 640 x 480 px resolution and up to 20 Hz reading rate, making it ideal for quality control, positioning, and verification tasks.

🔧 Technical Specifications:

• Type: Object Recognition / Proximity Sensor

• Accuracy: 100%

• Activation Current: 35 mA

• Active Area: 15 mm

• Image Sensor: Black & white CMOS

• Resolution: 640 × 480 pixels

• Light Type: Infrared (850 nm)

• Max. Reading Rate: 20 Hz

• Operating Voltage: 24 V DC

• Voltage Tolerance: ±10%

• Current Consumption: 300 mA

• Operating Temperature: -10°C to +60°C

• Protection Class: IP67, Class III

• Dimensions: 60 × 42 × 59 mm

• Reverse Polarity Protection: Yes

🧩 I/O Capabilities:

• Digital Inputs: 2 (24 V PNP, configurable; IEC 61131-2 Type 1)

• Digital Outputs: 5

• Trigger Input: 24 V PNP internal

✅ Key Features:

• Fast and accurate object detection and image analysis

• Infrared illumination ensures reliable performance in variable lighting

• Robust IP67 housing for harsh industrial environments

• Flexible I/O configuration for seamless integration

• High-resolution imaging for precise recognition and tracking

• Reverse polarity protection for safer operation

🏭 Ideal For:

• Automated visual inspection

• Robotics and pick-and-place systems

• Packaging lines and sorting applications

• Object detection in constrained or harsh conditions

Take your automation and quality control to the next level with this high-performance object recognition sensor, built to deliver reliable results in even the most demanding environments.
