OBE10M-18GM60-SE4 P&F Thru-Beam Sensor

Pepperl+Fuchs OBE10M-18GM60-SE4 | High-Performance Thru-Beam Sensor Pair (Red Light, IP67)

The OBE10M-18GM60-SE4 is a premium thru-beam sensor pair from Pepperl+Fuchs, engineered for high-precision detection and excellent environmental resistance. With its cylindrical stainless steel housing (M18 x 1) and IO-Link interface, this sensor provides reliable performance in industrial automation applications requiring long-range detection and rugged construction.

🔧 Technical Specifications:

• Brand: Pepperl+Fuchs

• Model Number: OBE10M-18GM60-SE4

• Sensor Type: Thru-beam sensor (Control Unit - Pair)

• Material: Stainless Steel

• Housing: Cylindrical with M18 x 1 thread

• Light Source: Red Light

• Sensing Range: 3 m to <10 m

• Switching Output: PNP, NC contact

• Response Time: 2 ms

• Switching Frequency: 500 Hz

• Supply Voltage: 10 – 30 V DC

• Interface: IO-Link

• Setting Method: Potentiometer

• Protection Class: IP67

• Operating Temperature: -40°C to +60°C

• Weight: Approx. 70 g

✅ Key Features:

• Very high detection range with fast response time (2 ms)

• Rugged stainless steel housing ideal for harsh industrial environments

• Compact M18 cylindrical design for space-efficient installation

• Ambient light immunity for consistent performance

• IP67 protection for dustproof and waterproof reliability

• Easy setup with potentiometer-based adjustment and IO-Link connectivity

🏭 Ideal Applications:

• Automation systems

• Conveyor lines

• Packaging machinery

• High-precision material detection

• Environments with dust, moisture, or variable lighting

Enhance your sensing capabilities with the OBE10M-18GM60-SE4 — a powerful and durable thru-beam sensor built for uncompromised industrial performance.
