OBE10M-18GM60-SE4-V1 P&F Thru-Beam Sensor

Pepperl+Fuchs OBE10M-18GM60-SE4-V1 | High-Performance Thru-Beam Sensor with IO-Link, IP67

The OBE10M-18GM60-SE4-V1 is a high-range thru-beam sensor pair from Pepperl+Fuchs, designed for precision detection even in challenging industrial environments. With IO-Link communication, rugged construction, and superior immunity to ambient light, this sensor is perfect for long-distance object detection up to 15 meters.

🔧 Technical Specifications:

• Brand: Pepperl+Fuchs

• Model Number: OBE10M-18GM60-SE4-V1

• Sensor Type: Thru-beam sensor (pair)

• Housing Material: PBT

• Light Source: Red light

• Range: 10 m to <15 m

• Switching Output: PNP

• Output Function: Inactive contact

• Switching Frequency: 500 Hz

• Housing Style: Cylindrical, Thread M18 x 1

• Supply Voltage: 10–30 V DC

• Operating Temperature: -25°C to +70°C

• Weight: 23 g

• Protection Class: IP67

• Interface: IO-Link

🌟 Key Features:

• Very high detection range up to 15 meters

• Strong metallic housing with M18 cylindrical thread for durable mounting

• Not sensitive to ambient light, ensuring reliable operation in various lighting conditions

• IO-Link interface for advanced diagnostics and easy integration into smart systems

• High switching frequency (500 Hz) for fast response in dynamic environments

• Robust IP67 protection, ideal for industrial automation applications

🏭 Application Areas:

• Material handling and logistics

• Packaging and labeling lines

• Robotics and conveyor systems

• Harsh or high-vibration industrial environments

Enhance your sensing solutions with the Pepperl+Fuchs OBE10M-18GM60-SE4-V1—a reliable, intelligent, and long-range thru-beam sensor built for modern industrial demands.
