OBE25M-18GM60-SE4 P&F Thru-beam sensor

Pepperl+Fuchs OBE25M-18GM60-SE4 | High-Range Thru-Beam Receiver Sensor (NPN, NC)

The OBE25M-18GM60-SE4 from Pepperl+Fuchs is a rugged and reliable thru-beam receiver sensor designed for long-range industrial detection. Built with a durable PBT housing and a metallic M18 cylindrical body, this sensor delivers high performance even in demanding environments. Ideal for use in automation, packaging, and object detection systems.

🔧 Technical Specifications:

• Brand: Pepperl+Fuchs

• Model Number: OBE25M-18GM60-SE4

• Sensor Type: Receiver (for thru-beam sensor pair)

• Material: PBT

• Light Source: Infrared Light

• Range: 10 m to <15 m

• Switching Output: NPN

• Contact Output: Normally Closed (NC)

• Connection: M8, 4-pin

• Interface: RS-232

• Housing Type: Cylindrical (M18 x 1 thread)

• Operating Temperature Range: -25°C to +60°C

• Protection Rating: IP67

🌟 Key Features:

• Very high detection range for long-distance applications

• Strong metallic housing ensures durability in harsh industrial environments

• Infrared light source for reliable object detection

• Not sensitive to ambient light, enhancing stability and precision

• Compact M18 cylindrical design for easy installation

• IP67 rated for superior protection against dust and water

• RS-232 interface for communication flexibility

✅ Ideal Applications:

• Conveyor systems

• Packaging lines

• Position and presence detection

• Automation and robotics

Pepperl+Fuchs OBE25M-18GM60-SE4 is your go-to sensor when long-range detection and industrial-grade durability are key.
