OBT500-18GM60-E4 P&F Diffuse mode sensor

P&F OBT500-18GM60-E4 | Compact Infrared Diffuse Mode Sensor

The OBT500-18GM60-E4 by P&F (Pepperl+Fuchs) is a high-precision infrared diffuse mode sensor designed for reliable object detection in industrial environments. With a compact design and sensing range up to 500 mm, it delivers dependable performance in space-restricted and demanding applications.

🛠️ Technical Specifications:

• Brand: Pepperl+Fuchs (P&F)

• Model No.: OBT500-18GM60-E4

• Sensor Type: Diffuse Mode Sensor

• Sensing Distance: 0 ... 500 mm

• Material: PBT

• Weight: 50 g

• Protection Rating: IP67 (Dust-tight & water-resistant)

• Reference Target: White, 200 mm x 200 mm

• Light Source: IRED (Infrared LED), 880 nm

• Light Type: Infrared

• Spot Diameter: Approx. 80 mm at 500 mm

• Ambient Light Limit: 10,000 Lux

🌟 Key Features:

• Compact and lightweight design for easy integration

• LED Indicators:

  • Green: Power ON

  • Yellow: Switch state

  • Flashing: Stability control

• Adjustable sensing range via control knob

• Reliable detection of standard and small objects

• Ideal for close-range sensing applications

• High immunity to ambient light interference

✅ Ideal For:

• Automation systems

• Robotics and assembly lines

• Packaging and conveyor systems

• Space-constrained installations requiring precision sensing

Experience stable, compact, and efficient sensing with the P&F OBT500-18GM60-E4 — the ideal choice for precision and reliability in industrial environments.
