Pepperl+Fuchs OBT500-18GM60-E5-V1 | High-Precision Infrared Photoelectric Sensor

The OBT500-18GM60-E5-V1 from Pepperl+Fuchs is a high-performance infrared diffuse mode sensor designed for demanding industrial automation environments. With a sensing distance up to 1000 mm and robust mild steel housing, it ensures accurate and stable object detection with exceptional durability.

🔧 Technical Specifications:

• Brand: Pepperl+Fuchs

• Model No.: OBT500-18GM60-E5-V1

• Sensing Distance: 0 to 1000 mm (Optimal: 0–500 mm)

• Material: Mild Steel

• Weight: 3 kg

• Color: Black

• Reference Target: White, 200 mm x 200 mm

• Light Source: IRED (Infrared LED), 880 nm

• Spot Diameter: ~80 mm at 500 mm

• Ambient Light Limit: 10,000 Lux

⚡ Electrical and Functional Features:

• Operating Voltage: 10–30 V DC (Class 2)

• Current Consumption: ≤ 25 mA

• Switching Frequency: 500 Hz

• Response Time: 1 ms

• Output: PNP, short-circuit and reverse polarity protected

• Switching Type: Light/Dark ON, electrically switchable

• Voltage Drop: ≤ 2.5 V

• Max Switching Current: 100 mA

🌟 Key Features:

• Dual-color LED for status indication:

  • Yellow: Switch state

  • Green: Power ON

  • Flashing: Stability control

• Adjustable sensing range for flexible use

• Sturdy mild steel housing ensures long life in industrial settings

• UL and CE certified for global compliance

• Quick availability with only 25 ms startup delay

✅ Ideal For:

• Factory and process automation

• Conveyor and packaging systems

• Robotics and handling technology

• Applications requiring long-range, high-precision object detection

Boost your automation reliability with the Pepperl+Fuchs OBT500-18GM60-E5-V1 — combining advanced infrared sensing, robust build quality, and smart diagnostics.
