OGD580 IFM Photoelectric Distance Sensor

IFM OGD580 Photoelectric Distance Sensor | Long Range PMD Technology

The IFM OGD580 is a high-performance photoelectric distance sensor featuring PMD time-of-flight technology and a compact M18-threaded housing. Designed for precision and durability, it offers long-distance measurement up to 60 meters with excellent accuracy, even on color-independent surfaces.

🔧 Technical Specifications:

• Brand: IFM

• Model No.: OGD580

• Sensor Type: Optical Photoelectric Distance Sensor

• Measurement Range: Up to 60 meters

• Measurement Center Point: 30 mA

• Supply Voltage: 10 – 30 V DC

• Supply Current: 20 mA

• Frequency: 50 / 60 Hz

• Ambient Operating Temperature: -20 to 75°C

• Working Temperature: -10 to 30 V

• Max Pressure: 100 Bar

• Protection Class: IP67

• Material: PBT

• Color: Orange

• Housing Type: Rectangular with M18 thread

• Laser Protection: Class 1

• Type of Light: Red light

🌟 Key Features:

• Time-of-flight (PMD) technology for precise distance measurement

• Extended sensing range up to 60 m

• Compact, space-saving design with standard M18 threading

• Reliable, color-independent detection

• Laser protection class 1 – ideal for safe use in industrial environments

• IP67-rated – protected against dust and water

✅ Applications:

• Automotive industry

• Industrial automation

• Object detection in logistics and packaging

• High-speed and long-range monitoring systems

Enhance your sensing systems with the IFM OGD580 – delivering long-range accuracy in a compact, rugged design built for demanding industrial environments.
