E3ZG-T61-L OMRON Photoelectric Sensor

Omron E3ZG-T61-L Photoelectric Sensor | Through-Beam Type | 15 m Sensing Distance

Enhance your automation system's accuracy and performance with the Omron E3ZG-T61-L Photoelectric Sensor. Built for reliability and precision, this through-beam type sensor offers long-range detection up to 15 meters with high stability. Ideal for industrial applications, it features a compact square design, fast response time, and robust PBT housing.

🔧 Key Specifications:

• Brand: Omron

• Model Number: E3ZG-T61-L

• Sensor Type: Photoelectric Sensor (Through-Beam Type)

• Product Type: Industrial Sensor

• Material: PBT

• Color: Black

• Shape: Square

• Weight: 120 g

📏 Performance Details:

• Sensing Distance: 15 m

• Standard Sensing Object: Opaque, 12 mm diameter min.

• Sensing Method: Through-beam

• Directional Angle: Emitter/Receiver: 3° to 15°

• Light Source: Infrared LED (870 nm)

⚡ Electrical Specifications:

• Power Supply Voltage: 12 to 24 VDC ±10%

• Ripple (p-p): 10% max.

• Current Consumption:

  • Emitter: 15 mA max.

  • Receiver: 20 mA max.

• Control Output:

  • Type: NPN Open Collector

  • Max Voltage: 26.4 VDC

  • Max Load Current: 100 mA

  • Residual Voltage:

    • ≤1 V (Load <10 mA)

    • ≤2 V (Load 10–100 mA)

✅ Why Choose the Omron E3ZG-T61-L?

• Reliable long-distance detection

• Durable and compact design

• Quick and easy installation

• Ideal for harsh industrial environments

• Energy-efficient with low current consumption

Upgrade your industrial automation setup with the Omron E3ZG-T61-L, designed to deliver precision and durability in demanding sensing environments.
