OPU209 IFM Photoelectric Fork Sensor

IFM OPU209 Photoelectric Fork Sensor – Reliable Detection with Robust Design

The IFM OPU209 is a high-precision photoelectric fork sensor, engineered for reliable object detection in demanding industrial environments. With its integrated transmitter and receiver, alignment is not required—simplifying installation and reducing setup time. Its durable design, featuring a fine light beam and IP67 protection, ensures consistent performance even in harsh conditions.

Key Specifications:

• Brand: IFM

• Model Number: OPU209 (OPU-FNKG/IO-LINK/AS)

• Sensor Type: Photoelectric Fork Sensor

• Material: PVC

• Color: Black

• Accuracy: 100%

• Activation Current: 30 mA

• Active Area (Fork Width): 50 mm

• Fork Depth: 55 mm

• Operating Temperature: -25°C to +60°C

• Dimensions (L x W x H): 70 x 10 x 80 mm

• Weight: 1225 g

• Protection Rating: IP67

Features & Benefits:

• Plug-and-Play Setup: No need to align the transmitter and receiver

• High Precision: Stable and focused light beam across full fork width

• Durable Build: Metal housing design minimizes distortion and enhances longevity

• Adjustable Operation: Light-on/dark-on modes selectable via rotary switch

• Easy Calibration: Sensitivity can be finely adjusted via potentiometer

• IO-Link Compatible: Enables smart configuration and real-time diagnostics

Achieve fast and accurate detection with the IFM OPU209, the dependable sensor built for industrial precision.
