OPU701 IFM Photoelectric Fork Sensor

IFM OPU701 Photoelectric Fork Sensor – Compact, Precise & Application-Ready

The IFM OPU701 photoelectric fork sensor offers fast, reliable detection in compact automation environments. Built with PBT housing and designed to detect even the smallest objects, this sensor simplifies setup and ensures consistent performance across a wide range of industrial applications.

Product Highlights:

• Brand: IFM

• Model No.: OPU701 (OPULFPKG/IO-Link/AS)

• Sensor Type: Photoelectric Fork Sensor

• Material: PBT

• Type of Light: Red Light

• Laser Class: Class 1

• Accuracy: 100%

• Active Area: 10 mm

• Activation Current: 20 mA

• Operating Voltage: 10–30 V

• Wavelength: 655 nm

• Operating Temperature: -15°C to +55°C

• Ambient Temperature: -25°C to +60°C

• Protection Class: IP67

Key Features:

• Easy Setup: No need to align the transmitter and receiver

• High Precision: Reliable detection of small or fast-moving objects

• Self-Monitoring: Detects soiling through light quantity monitoring

• Customizable: Supports multiple operating modes via IO-Link

• Rugged & Compact: Ideal for use in space-restricted and harsh environments

Designed for seamless integration into modern automation systems, the OPU701 delivers dependable performance with minimal maintenance.
