PA1-F-150 Gefran Linear Transducer

Gefran PA1-F-150-S01M Linear Potentiometer | 150 mm Stroke | ±0.05% Linearity

The Gefran PA1-F-150-S01M is a high-precision linear potentiometer designed for demanding measurement and test applications. With a robust anodized aluminum body, precise linear output, and reliable performance in industrial environments, this sensor is ideal for accurate position feedback and displacement measurement.

Key Features:

• Travel Length: 150 mm

• Independent Linearity: ±0.05%

• Tolerance: ±1%

• Resistance Value: 5 kΩ

• Voltage: Up to 60V

• Material: Anodized Aluminium

• Part Number: PA1-F-150-S01M

• Size/Dimension: 150 mm

• Temperature Range: -30°C to +100°C

• IP Rating: IP40 – Protected against solid objects larger than 1 mm

Mechanical Details:

• Mechanical Linkage: Joint with take-up of play

• Thread Type: M4

• Construction: Durable, corrosion-resistant anodized aluminum housing

• Usage/Application: Measurement and Test Equipment, Automation Systems, Industrial Machinery

Why Choose the Gefran PA1-F-150-S01M?

• Precision engineering with ultra-low linearity error

• Compact and rugged design ideal for industrial environments

• Smooth mechanical operation with anti-play joints

• Reliable performance in temperature-extreme conditions

Enhance the accuracy of your measurement systems with the Gefran PA1-F-150-S01M linear potentiometer — built for precision and durability
