IFM PA3020 Pressure Transmitter | 0–10000 PSI | Industrial-Grade Sensor

The IFM PA3020 pressure transmitter delivers exceptional accuracy and durability for industrial pressure monitoring tasks. Equipped with a ceramic measuring cell and built with a rugged stainless steel housing, this transmitter ensures reliable performance even in the toughest environments.

Product Highlights:

• Measurement Range: 0–10000 psi

• Accuracy: 100%

• Output Signal: Analog 4–20 mA

• Output Type: PNP

• Voltage Range: 9.6–32 V DC

• Rated Supply Voltage: 10–30 V

• Response Time: 2 ms

• Protection Rating: IP67

• Model Number: PA3020 (PA-400-SBR14-A-ZVG/US/V)

• Material: Stainless Steel

• Color: Silver

• Product Weight: 222.5 g

• Dimensions: Ø30 mm / L = 75 mm

• Minimum Pressure Cycles: 100 million

• Application: Industrial environments

Key Features:

• Precise linear 4–20 mA output for accurate monitoring

• High repeatability with minimal linearity error

• Overload protection ensures long-term reliability

• Fast 2 ms response time for real-time data capture

• IP67 stainless steel body for harsh operating conditions

• Wide voltage and temperature tolerance

Engineered for reliability. The IFM PA3020 is the ideal solution for demanding industrial applications requiring precise pressure measurement and long-lasting durability.
