PA3029 IFM Pressure Transmitter

IFM PA3029 Pressure Transmitter – 0–5000 PSI, 4–20 mA Output, IP67 Rated

The IFM PA3029 pressure transmitter is designed to deliver accurate, stable, and repeatable pressure measurement in industrial environments. Built with a ceramic measuring cell and a rugged stainless steel housing, it ensures reliable performance even under high pressure and harsh conditions.

Key Features:

• Measurement Range: 0–5000 psi

• Accuracy: 100%

• Output Signal: Analog 4–20 mA

• Response Time: 5 ms

• Voltage Range: 12–32 V DC

• Rated Supply Voltage: 10–30 V

• Supply Voltage Limits: Up to 32 V

• Output Type: PNP

• Protection Type: IP67

• Material: Stainless Steel

• Product Weight: 222 g

• Color: Silver

• Model Number: PA3029 (PA-0-1-RBR14-A-ZVG/US/V)

• Application: Industrial pressure sensing

Product Advantages:

• Precise Linear Output (4–20 mA): Ensures accurate signal transmission

• High Repeatability & Low Linearity Error: Delivers reliable and consistent readings

• Robust Construction: Stainless steel housing withstands harsh industrial environments

• Ceramic Measuring Cell: Provides high overload protection and long-term stability

• Wide Operating Temperature Range & IP67 Protection: Suitable for demanding applications

Upgrade your industrial systems with the IFM PA3029 Pressure Transmitter — delivering durability, precision, and trusted performance under pressure.
