PA3060 IFM Pressure Transmitter | Industrial Pressure Sensor – KMSPARE

IFM PA3060 Pressure Transmitter – 0–5000 PSI, 4–20 mA Output, IP67 Rated

The IFM PA3060 pressure transmitter is engineered for precision and long-term performance in demanding industrial environments. Featuring a robust stainless steel body and ceramic measuring cell, this transmitter delivers reliable pressure monitoring even under extreme conditions.

Key Features:

• Measurement Range: 0–5000 psi

• Accuracy: 100%

• Output Signal: Analog 4–20 mA

• Response Time: 10 ms

• Voltage Range: 10–30 V DC

• Rated Supply Voltage: 10–30 V

• Protection Type: IP67

• Protection Class: III

• Material: Stainless Steel

• Product Weight: 232 g

• Color: Silver

• Model Number: PA3060 (PA-600-SBR14-A-ZVG/US/V)

• Application: Industrial pressure monitoring

Advantages:

• Ceramic Measuring Cell: Offers high overload protection and stability

• Excellent Repeatability & Low Linearity Error: For precise and consistent readings

• Rugged Design: Built to operate in harsh industrial conditions

• Fast Response Time: Enables accurate real-time monitoring

• Wide Temperature Range & Strong Environmental Protection: IP67 rating ensures resistance to dust and water

Enhance your industrial system’s reliability with the IFM PA3060 Pressure Transmitter — built for accuracy, built to last.
