PA3221 IFM Pressure Transmitter

IFM PA3221 Pressure Transmitter – 0–1000 PSI, 4–20 mA Output, IP68

The IFM PA3221 pressure transmitter is a high-performance solution designed for precise and stable pressure measurement in industrial environments. Engineered with a ceramic measuring cell and stainless steel housing, it ensures durability, accuracy, and reliability in demanding conditions.

Key Features:

• Measurement Range: 0–1000 psi

• Accuracy: 100%

• Output Signal: Analog 4–20 mA

• Voltage Range: 12–24 V DC

• Rated Supply Voltage: 30 V

• Response Time: 1 ms

• Protection Type: IP68 (Dust-tight and immersion-resistant)

• Material: Stainless Steel

• Color: Silver

• Weight: 226 g

• Model Number: PA3221 (PA-250-SBN14-A-ZVG/US/V)

• Application: Industrial pressure monitoring and control

Product Highlights:

• Precise Linear Output (4–20 mA): Delivers accurate real-time pressure readings

• High Repeatability & Low Linearity Error: Ensures consistent performance

• Robust Overload Protection: Supports long-term operational stability

• Rugged Design: Built for harsh industrial use with IP68 protection

• Wide Operating Temperature Capability: Performs reliably in extreme environments

Enhance the efficiency and safety of your industrial systems with the IFM PA3221 Pressure Transmitter—a robust and precise sensor solution built to last.
