PA3524 IFM Pressure Transmitter

IFM PA3524 Pressure Transmitter – 0–1000 PSI, 4–20 mA Output, IP67, PNP, Stainless Steel

Engineered for precision and durability, the IFM PA3524 pressure transmitter is ideal for demanding industrial applications. Equipped with a ceramic measuring cell and a robust stainless steel housing, this transmitter ensures high performance, even in harsh conditions.

Key Features:

• Measurement Range: 0–1000 psi

• Output Signal: Precise 4–20 mA linear analog

• Output Type: PNP

• Accuracy: 100%, with minimal linearity error

• Response Time: Fast 10 ms

• Rated Supply Voltage: 10–30 V DC

• Operating Voltage Range: 9.6–32 V DC

• Supply Voltage Limit: Up to 32 V

• Min. Bursting Pressure: 150 Bar

• Protection Type: IP67 – excellent protection against dust and water ingress

• Material: Stainless steel housing for durability in industrial settings

• Color: Silver

• Weight: 222 g

Model Details:

• Model Number: PA3524 (PA-010-RBG14-A-ZVG/US/V)

• Brand: IFM

• Technology: Ceramic pressure measuring cell

• Application: Designed for industrial automation, hydraulic systems, and process control

Why Choose the IFM PA3524:

• High repeatability and long-term stability

• Withstands high overload and burst pressure

• Suitable for a wide operating temperature range

• Compact cylindrical housing (30 mm Ø / Length 75 mm)

• Built to perform in harsh industrial environments

Whether you're upgrading your automation system or designing from scratch, the IFM PA3524 delivers consistent, reliable pressure readings with outstanding performance.
