FX-501-C2 Panasonic Fiber Optic Sensor

Voltage 10-30V Brand Panasonic Type Fiber Optics Sensor Heads Light Source Red LED Interface IO-Link Model Number FX-501-C2 Switching Frequency 50/ 60 Hz Switching Output PNP Housing M8 Housing Material CuZu Nickel Plated Degree of Protection IP68 Operating Temperature -40 to 125 Deg C No Load Supply Current 40 mA Supply voltage UB 10 ......... 30 V Model No. FX-501-C2 Product type Sensor Sensor Type Digital Fiber Optic Sensor Color Black Weight 75 g Temperature -20 ....... 70 C Shock resistance 98 m/s2 Product Number FX-501 Part Number FX-501 Products Name Digital Fiber Sensor Product details Standard type Applicable regulations and certifications CE Marking (EMC Directive, RoHS Directive), UKCA Marking (EMC Regulations, RoHS Regulations), UL/c-UL Listing certification Supply voltage 12 to 24 V DC+10-15 % Ripple P-P 10 % or less Power consumption Normal operation: 960 mW or less (current consumption 40 mA or less at 24 V supply voltage) ECO mode: 680 mW or less (current consumption 28 mA or less at 24 V supply voltage) Output NPN open-collector transistor - Maximum sink current: 100 mA (Note 1) - Applied voltage: 30 V DC or less (between output and 0 V) - Residual voltage: 2 V or less (Note 2) (at maximum sink current) (Note 1) 50 mA max. if 5 or more standard types are connected together. (Note 2) 50 mA max. if 5 or more standard types are connected together. (25 mA in case of 2-output type and cable type)
