FX-551-C2 Panasonic Fiber Optic Sensor

Voltage 10-30V Brand Panasonic Type Fiber Optics Sensor Heads Light Source Red LED Interface IO-Link Model Number FX-551-C2 UFX551C2 Product Number FX-551-C2 Part Number FX-551-C2 Applicable regulations CE Marking (EMC Directive, RoHS Directive), UKCA Marking (EMC Regulations, RoHS Regulations) Supply voltage 12 to 24 V DC +10-15 % Ripple P-P 10 % or less Power consumption Normal operation : 960 mW or less (current consumption 40 mA or less at 24 V supply voltage) ECO mode : 680 mW or less (current consumption 28 mA or less at 24 V supply voltage) Output NPN open-collector transistor ?Maximum sink current : 100 mA ?Applied voltage : 30 V DC or less (between output and 0 V) ?Residual voltage : 2 V or less (at maximum sink current) Output:Output operation Switchable either Light-ON or Dark-ON by L/D mode Output:Short-circuit protection Incorporated Response time FAST : 60?s or less, STD : 250?s or less, LONG : 2ms or less, U-LG : 4ms or less, HYPR : 24ms or less, selectable Sensitivity setting 2-point teaching / Limit teaching / Full-auto teaching / Manual adjustment Incident light sensitivity setting Incorporated, 4 steps
