PI2203 IFM Flush Pressure Sensor

Type Vacuum Suitable Media Water Part Number PI2203 Brand IFM Pressure Range -1 TO 25 bar Response Time 45ms Output 2 Digital (PNP/NPN) & 1 Analog (4-20mA) Supply Voltage 18-32VDC Interface I/O Link Housing Material Stainless Steel Process Connection Clamp DN40 (1,5") DIN 32676 (ISO 2852) Operating Temperature -25 TO 80 DEGREE IP Protection Class IP69K For use in high temperatures in the food and beverage industry Robust stainless steel housing with hygienic front-flush design With two-wire and three-wire connection technology Reduced wiring complexity when operated as two-wire current loop Integrated clamp diaphragm seal with stainless steel membrane
