PK6224 IFM Pressure Switch

Number of inputs and outputs Number of digital outputs: 2 Measuring range 0...10 bar 0...145 psi Process connection threaded connection 1/4" NPT external thread internal thread:M5 Application Application for industrial applications Media liquids and gases Medium temperature[°C] -25...80 Min. bursting pressure 300 bar 4350 psi 30 MPa Pressure rating 25 bar 362 psi 2.5 MPa Type of pressure relative pressure MAWP for applications according to CRN 25 bar 362 psi Electrical data Operating voltage[V] 9.6...32 DC Current consumption[mA] < 25 Min. insulation resistance[M?] 100; (500 V DC) Protection class III Reverse polarity protection yes Inputs / outputs Number of inputs and outputs Number of digital outputs: 2 Outputs Total number of outputs 2 Output signal switching signal Electrical design PNP Number of digital outputs 2 Output function complementary Max. voltage drop switching output DC[V] 2 Permanent current rating of switching output DC[mA] 500 Switching frequency DC[Hz] 100 Short-circuit protection yes Type of short-circuit protection pulsed Overload protection yes
