PM-R25 Panasonic Photoelectric Sensor

Panasonic PM-R25 | Ultra-Small U-Shaped Photoelectric Sensor [Amplifier Built-in, R Type]

The Panasonic PM-R25 is an ultra-compact, cable-type micro photoelectric sensor featuring a built-in amplifier and reliable detection performance. Engineered for space-saving installations, it is an ideal choice for compact automation setups and precision assembly environments.

🔧 Technical Specifications:

• Model No.: PM-R25

• Brand: Panasonic

• Sensor Type: U-shaped Photoelectric Sensor (R Type)

• Material: PBT

• Accuracy: 100%

• Activation Current: 30 mA

• Current Consumption: 15 mA or less

• Operating Voltage: 5 to 24 V DC ±10%

• Active Area: 10 mm

• Operating Temperature: -25°C to +55°C

• Product Type: Amplifier Built-in / Cable type

• Weight: Compact and lightweight design

✅ Key Features:

• Ultra-Small Housing: Designed for applications with limited mounting space

• Built-in Amplifier: No external amplifier needed, simplifies wiring and setup

• Durable PBT Construction: Offers excellent resistance to harsh environments

• Reliable Object Detection: Accurately detects small opaque objects

• Certifications & Standards:

  • CE (EMC & RoHS Directive)

  • UKCA (EMC & RoHS Regulations)

  • ISO 13849-1 (Category 1, PLc compliant)

  • UL/c-UL Recognized

Typical Applications:
Miniature conveyor systems, pick-and-place machines, robotic arms, PCB assembly lines, and other space-constrained industrial applications.
