PM-R65 Panasonic Photoelectric Sensor

Panasonic PM-R65-P | U-Shaped Micro Photoelectric Sensor with Built-in Amplifier (R Type)

The Panasonic PM-R65-P is a compact and highly reliable photoelectric sensor designed for precision detection in tight spaces. Featuring an integrated amplifier and connector-type build, it offers exceptional performance for industrial automation applications.

🔧 Product Highlights:

• Model: PM-R65-P

• Brand: Panasonic

• Product Type: Photoelectric Sensor (Amplifier Built-in)

• Sensor Type: U-Shaped Micro Sensor [R Type]

• Material: PBT

• Color: Black

• Weight: 3 g

• Operating Temperature: -25°C to +55°C

• Protection Class: IP40

• Power Supply: 5 to 24 V DC ±10%

• Current Consumption: ≤ 15 mA

• Activation Current: 20 mA

• Active Area: 30 mm

• Sensing Range: 6 mm (Fixed)

• Minimum Sensing Object: 0.8 × 1.2 mm opaque object

• Hysteresis: ≤ 0.05 mm

• Repeatability: ≤ 0.01 mm

• Ripple (P-P): ≤ 10%

✅ Key Features:

• Compact, space-saving design ideal for tight installation spaces

• Built-in amplifier and connector for easy integration

• High detection accuracy with excellent repeatability

• Certified for CE, UKCA, RoHS, and UL/c-UL standards

• Perfect for precise detection of small opaque objects

Applications:
Ideal for electronics assembly, robotic automation, conveyor systems, and miniature equipment requiring accurate object detection.
