PM1608 IFM Flush Pressure Sensor | Hygienic Pressure Measurement – KMSPARE

Measurement Range 0-1000 psi Brand IFM Voltage 18...30 DC Minimum Pressure Reading 30000 mbar Pressure Range 6000 mbar Accuracy 100% Rated Supply Voltage 30DC Moedel No. PM1608 Number of inputs and outputs Number of digital outputs: 1; Number of analogue outputs: 1 Measuring range -0.0125...0.25 bar -12.5...250 mbar -0.182...3.626 psi -1.25...25 kPa Process connection threaded connection G 1 external thread sealing cone Application Special feature Gold-plated contacts Measuring element ceramic-capacitive pressure measuring cell Temperature monitoring no Application flush mountable for the food and beverage industry Media viscous media and liquids with suspended particles; liquids and gases Medium temperature [°C] -25...150 Min. bursting pressure 30000 mbar 435 psi 3000 kPa Pressure rating 6000 mbar 84 psi 600 kPa Vacuum resistance [mbar] -1000 Type of pressure relative pressure No dead space yes MAWP (for applications according to CRN) [bar] 10
