PM2-LH10 Panasonic Photoelectric Sensor

Panasonic PM2-LH10 Convergent Reflective Micro Photoelectric Sensor | Top Sensing | Compact & Precise

The Panasonic PM2-LH10 is a high-precision convergent reflective micro photoelectric sensor designed for compact spaces and demanding industrial applications. With top sensing functionality, this sensor is ideal for detecting small objects with exceptional accuracy, even in tight installations.

🔍 Key Specifications:

• Model: PM2-LH10

• Brand: Panasonic

• Product Type: Photoelectric Sensor

• Sensor Style: Convergent Reflective, Top Sensing

• Material: PBT

• Active Area: 10 mm

• Operating Temperature: -10 to +50°C

• Weight: 85 g

• Power Supply: 5 to 24 V DC ±10% (Ripple P-P 5% or less)

📏 Performance Highlights:

• Sensing Range: 2.5 to 8 mm (Convergent point: 5 mm) with white non-glossy paper

  • Note: May extend up to 12.5 mm depending on object/material

• Minimum Sensing Object: Ø0.05 mm copper wire

• Repeatability: ≤ 0.08 mm (with white non-glossy paper, perpendicular axis)

• Hysteresis: ≤ 20% of operating distance

✅ Features & Benefits:

• Compact design for micro-level detection

• Accurate detection of very small objects

• Top sensing orientation ideal for flat-mount applications

• Low power consumption

• Stable performance in varied lighting conditions

📦 Applications:

• Electronics assembly lines

• High-speed packaging systems

• Precision object detection

• Semiconductor manufacturing

Note: For pricing and volume discounts, please contact our office directly.

Equip your automation systems with the Panasonic PM2-LH10 — where precision meets reliability in a miniature sensor form factor.
