PN2024 IFM Pressure Sensor

IFM Pressure Sensor | -1 to 10 bar | Dual Digital + Analog Output | IO-Link Compatible

Compact. Accurate. Intelligent – Built for Industrial Fluid and Gas Monitoring

This IFM pressure sensor is engineered for reliable pressure monitoring in demanding industrial applications. It features gold-plated contacts, configurable digital and analog outputs, and advanced IO-Link communication, making it ideal for modern automation systems.

✅ Key Features:

• Measuring Range:

  • -1 to 10 bar

  • -14.5 to 145 psi

  • -100 to 1000 kPa

  • -0.1 to 1 MPa

• Pressure Type: Relative

• Rated Pressure: 75 bar (1088 psi)

• Bursting Pressure: 150 bar (2175 psi)

• Media Compatibility: Liquids and gases

• Medium Temperature: -25°C to +80°C

• Process Connection: G 1/4 internal thread (DIN standard)

⚙️ Electrical & Output Details:

• Operating Voltage: 18–32 V DC (SELV/PELV compliant)

• Current Consumption: < 35 mA

• Protection Class: III

• Reverse Polarity Protection: Yes

• Integrated Watchdog Function: Yes

• Power-On Delay: 0.3 s

• Outputs:

  • 2 x Digital Outputs

    • PNP/NPN configurable

    • Normally Open/Closed (parameterisable)

    • Switching frequency: < 500 Hz

    • Max. current: 250 mA

  • 1 x Analog Output

    • Current: 4–20 mA (scalable 1:4)

    • Voltage: 0–10 V (scalable 1:4)

    • Max. Load: (Ub - 10 V) / 20 mA

    • Min. Load Resistance: 2000 Ω

  • Communication: IO-Link (configurable)

• Output Signals:

  • Switching signal

  • Analog signal

  • IO-Link (COM2 protocol)

🔒 Protection & Durability:

• Short-Circuit Protection: Pulsed

• Overload Protection: Yes

• Insulation Resistance: > 100 MΩ (at 500 V DC)

• Gold-Plated Contacts: Ensures reliable signal transmission in tough environments

🛠️ Applications:

• Pneumatic and hydraulic systems

• Process automation

• Monitoring of pressure in pipelines and tanks

• OEM industrial solutions

• Gases and liquids in pressurized systems

Ready for Industry 4.0 integration, this IFM pressure sensor offers robust performance, high electrical reliability, and flexible configuration – perfect for demanding automation environments.
