PN2070 IFM Pressure Sensor | Industrial Pressure Sensor – KMSPARE

IFM High-Pressure Sensor | 0–250 bar | IO-Link + Analog + Dual Digital Outputs | G 1/4 Thread

Precision Meets Performance – Designed for Extreme Industrial Applications

This high-performance IFM pressure sensor delivers precise pressure monitoring in demanding industrial environments, supporting liquids and gases up to 250 bar (3625 psi). With IO-Link communication, configurable analog and digital outputs, and rugged construction, it's ideal for high-load applications requiring superior stability and response times.

✅ Key Features:

• Pressure Measuring Range:

  • 0 to 250 bar

  • 0 to 3625 psi

  • 0 to 25 MPa

• Pressure Type: Relative pressure

• Vacuum Resistance: -1000 mbar (-0.1 MPa)

• Rated Pressure: 500 bar (7250 psi)

• Bursting Pressure: 1200 bar (17400 psi)

• Sensor Element: Metallic thin-film measuring cell

• Gold-Plated Contacts: Enhanced electrical performance

⚙️ Electrical & Output Specifications:

• Operating Voltage: 18–30 V DC (SELV/PELV)

• Current Consumption: < 35 mA

• Protection Class: III

• Reverse Polarity Protection: Yes

• Short-Circuit & Overload Protection: Pulsed / Built-in

• Power-On Delay: 0.3 s

• Integrated Watchdog Function

• Outputs:

  • 2 Digital Outputs:

    • PNP/NPN configurable

    • Normally open/closed (parameterisable)

    • Switching frequency: < 500 Hz

    • Max current: 250 mA

  • 1 Analog Output:

    • Current: 4–20 mA (max 500 Ω)

    • Voltage: 0–10 V (min 2000 Ω)

    • Scalable output (1:5 ratio)

  • IO-Link Communication:

    • COM2, 38.4 kBaud

    • IO-Link Revision 1.1

    • Smart Sensor Profile 3.1

📏 Performance & Accuracy:

• Switch Point Accuracy: < ±0.4% of span

• Repeatability: < ±0.1%

• Linearity (BFSL): < ±0.25%

• Long-Term Stability: < ±0.05% per 6 months

• Response Time (Switching): < 1.5 ms

• Analog Response Time: < 3 ms

• Damping (Settable): 0–4 s

🛠️ Process & Installation:

• Connection: G 1/4 internal thread (DIN EN ISO 1179-2)

• Medium Temperature: -25°C to +80°C

• Ambient Temp: -25°C to +80°C

• Storage Temp: -40°C to +100°C

• Protection Rating: IP65 & IP67

• Rotatable Sensor Head for flexible installation

📦 Applications:

• Hydraulic systems & high-pressure machinery

• Industrial automation

• OEM systems

• Pressure control in liquid and gas pipelines

• Smart monitoring via IO-Link

Engineered by IFM for industrial reliability, this sensor guarantees high-accuracy pressure monitoring even in the harshest environments. Perfect for next-generation automation, with scalable analog output and high-resolution digital control.
