PN2092 IFM Pressure Sensor

IFM Pressure Sensor | 0–100 bar | IO-Link + Analog Output | Dual Digital Outputs | G 1/4 Thread

Reliable Pressure Sensing for High-Performance Industrial Applications

This IFM pressure sensor is engineered for robust industrial use, offering high-precision measurement up to 100 bar (1450 psi). With IO-Link compatibility, analog and dual digital outputs, and a ceramic-capacitive measuring element, it ensures exceptional stability, overload protection, and flexibility in demanding environments.

✅ Key Features:

• Measuring Range:

  • 0 to 100 bar

  • 0 to 1450 psi

  • 0 to 10 MPa

• Pressure Type:

  • Relative pressure

  • Vacuum resistance: -1000 mbar (-0.1 MPa)

  • Max Pressure Rating: 300 bar (4350 psi)

  • Bursting Pressure: 650 bar (9400 psi)

• Suitable Media:

  • Liquids

  • Gases (conditionally suitable for use above 25 bar – upon request)

• Sensor Technology:

  • Ceramic-capacitive pressure measuring cell

  • Gold-plated contacts for improved signal reliability

⚙️ Outputs & Electrical Specs:

• Total Outputs: 3

  • 2 Digital Outputs:

    • PNP/NPN configurable

    • Output mode: Normally open / normally closed

    • Max current: 250 mA

    • Switching frequency: < 500 Hz

  • 1 Analog Output:

    • Current: 4–20 mA (max load: 500 Ω)

    • Voltage: 0–10 V (min load: 2000 Ω)

    • Scalable 1:5 range

  • IO-Link: Supported (for enhanced data communication and configuration)

• Operating Voltage: 18–30 V DC

• Current Consumption: < 35 mA

• Protection & Safety:

  • Reverse polarity protection

  • Short-circuit protection (pulsed)

  • Overload protection

  • Protection Class: III

  • Integrated watchdog

  • Power-on delay: 0.3 s

🛠️ Mechanical & Environmental:

• Process Connection:

  • G 1/4 internal thread (DIN EN ISO 1179-2)

  • Rotatable for flexible installation

• Medium Temperature Range:

  • -25°C to +80°C

• Industrial Design:

  • Built for long-term performance in harsh environments

  • Excellent signal stability and high overload capacity

📦 Recommended Applications:

• Hydraulic & pneumatic systems

• Industrial machinery and automation

• Process monitoring in fluid systems

• OEM equipment and high-pressure lines

A versatile and durable solution for advanced pressure monitoring—trusted in industrial environments where reliability matters. Built by IFM for performance, precision, and productivity.
