PN3022 IFM Pressure Sensor

IFM High-Performance Pressure Sensor | 0–100 Bar | IO-Link Enabled | Stainless Steel Body

Accurate, Durable, and IO-Link Ready – Built for Industrial Excellence

Engineered for precision and reliability, this IFM Pressure Sensor is designed to meet the demands of high-pressure liquid and gas applications in industrial settings. With a rugged stainless steel body, gold-plated contacts, and advanced output capabilities, it offers dependable performance in even the most challenging environments.

Key Features:

• Measuring Range:
  0...100 bar | 0...1450 psi

• Pressure Rating:
  Rated for 300 bar operating pressure
  Withstands up to 650 bar bursting pressure

• Output Configuration:

  • 1 Digital Output (PNP)

  • 1 Analog Output (4–20 mA / 0–10 V)

  • IO-Link Communication for smart integration and remote configuration

• Electrical Specifications:

  • Supply Voltage: 20–30 V DC

  • Max Load: 500 Ω

  • Electrical Design: PNP

Mechanical & Environmental Highlights:

• Media Compatibility:
  Suitable for liquids and gases
  Note: For gaseous media, limited to max. 25 bar

• Temperature Range:

  • Medium: -25°C to +80°C

  • Ambient: -40°C to +105°C

• Process Connection:
  G 1/4 internal thread – standard for industrial applications

• Protection Class:
  IP67 – Dust-tight and water-resistant for harsh environments

• Housing Material:
  Corrosion-resistant Stainless Steel for enhanced durability

Special Features:

• Gold-Plated Contacts for reliable signal transmission

• Clearly visible status display

• Ideal for industrial automation, fluid control systems, hydraulics, and pneumatics

This IFM Pressure Sensor is your go-to solution for precise, stable pressure monitoring in high-demand industrial operations. With dual output options, IO-Link interface, and robust build, it guarantees long-lasting performance.
