PN5000 IFM Pressure Sensor

Industrial Pressure Sensor | 0–400 bar | PNP Output | G 1/4 Thread | LED Display

Reliable High-Pressure Monitoring for Industrial Applications

Engineered for precision, performance, and long-term stability, this digital pressure sensor is designed to handle extreme pressures up to 400 bar (5800 psi). Suitable for both liquids and gases, it’s the ideal choice for demanding industrial environments where accuracy and durability are critical.

Key Features:

• Wide Measuring Range:
  0...400 bar | 0...5800 psi | 0...40 MPa
  (Use with gases >25 bar only on request)

• Output Configuration:

  • 1 Digital Output (PNP)

  • Configurable output signal: NO/NC

  • Switching signal output

  • Max. switching current: 250 mA

  • Max. voltage drop: < 2 V

  • Switching frequency: < 170 Hz

• Setpoint & Reset Point Range:

  • Setpoint (SP): 4...400 bar

  • Reset point (rP): 2...398 bar

  • Resolution: 2 bar | 30 psi | 0.2 MPa

  • Factory setting: SP1 = 100 bar, rP1 = 92 bar

Electrical Specifications:

• Operating Voltage: 18–36 V DC (SELV/PELV compliant)

• Current Consumption: < 50 mA

• Built-in Protections:

  • Reverse polarity protection

  • Overvoltage protection (< 40 V)

  • Short-circuit protection (pulsed)

  • Integrated watchdog

  • Power-on delay: 0.3 s

  • Protection Class: III

Performance & Accuracy:

• Switch Point Accuracy: < ±0.5% of span

• Repeatability: < ±0.1%

• Characteristics deviation (BFSL): < ±0.25%

• Long-term stability: < ±0.05% per 6 months

• Temperature coefficient (zero/span): 0.2% / 10 K

Mechanical & Environmental Specs:

• Process Connection: G 1/4 internal thread

• Pressure Rating: 600 bar (8700 psi)

• Bursting Pressure: 1000 bar (14500 psi)

• Medium Temperature: -25 to 80 °C

• Ambient Temperature: -20 to 80 °C

• Storage Temperature: -40 to 100 °C

• Protection Class: IP67

• Media Compatibility: Liquids and gases

• Durability: Over 100 million pressure cycles

• Special Feature: Gold-plated contacts

User Interface & Configuration:

• 4-digit bright LED display for clear pressure readings

• Country-specific pressure units (bar, psi, MPa) selectable

• Memory function for highest system pressure recorded

• Programmable settings:

  • Hysteresis/window mode

  • NO/NC switching logic

  • Switch-on/off delay

  • Damping function

This sensor is built for rugged industrial tasks, offering unmatched reliability, accuracy, and ease of integration. A trusted choice for high-pressure system monitoring in automation, hydraulics, and process control applications.
