PN7001 IFM Pressure Sensor

Digital Pressure Sensor – 0...250 bar | IO-Link | Dual Output | G 1/4 Thread

Precision pressure monitoring with robust performance for industrial environments.

This digital pressure sensor is designed to deliver high accuracy and reliability in a wide range of industrial applications involving liquids and gases. With advanced features including IO-Link support, gold-plated contacts, and excellent long-term stability, it's ideal for systems requiring dependable pressure control up to 250 bar.

Key Features:

• Pressure Measuring Range:
  0...250 bar | 0...3625 psi | 0...25 MPa
  (Conditionally suitable for gases above 25 bar – contact us for special applications)

• Output Signals:
  2 configurable digital outputs (PNP/NPN)
  IO-Link communication included
  Normally open / normally closed (parameterizable)

• Setpoints & Factory Settings:

  • SP range: 2...250 bar

  • rP range: 1...249 bar

  • Factory Setpoints:

    • SP1 = 63 bar, rP1 = 58 bar

    • SP2 = 188 bar, rP2 = 183 bar

• Display:
  Bright 4-digit LED display with selectable pressure units (bar, psi, MPa)

Performance & Accuracy:

• Switch Point Accuracy: < ±0.5% of span

• Repeatability: < ±0.1%

• Deviation (BFSL/Limit): < ±0.25% / < ±0.5%

• Hysteresis Deviation: < ±0.25%

• Temperature Coefficient: 0.2% per 10 K (0...80 °C)

• Long-Term Stability: < ±0.05% per 6 months

• Response Time: Programmable delay 0 to 50 s

• Switching Frequency: < 170 Hz

Electrical & Protection Specifications:

• Operating Voltage: 18...36 V DC (SELV/PELV compliant)

• Current Consumption: < 35 mA

• Protection Class: III

• Overvoltage Protection: < 40 V

• Reverse Polarity & Short-Circuit Protection: Yes (pulsed)

• Max Switching Output: 250 mA

• Voltage Drop: < 2 V

• Integrated Watchdog: Yes

• Power-On Delay: 0.3 s

Mechanical & Environmental Details:

• Process Connection: G 1/4 internal thread

• Housing: Cylindrical – Ø34 mm x L 91.5 mm

• Materials:

  • Wetted parts: Stainless steel (303/1.4305), ceramics, FKM

  • Housing: PA, PBT, PC, PTFE, EPDM/X, stainless steel (304/1.4301)

• Pressure Rating: 400 bar (5800 psi / 40 MPa)

• Burst Pressure: 850 bar (12300 psi / 85 MPa)

• Temperature Range:

  • Medium: -25 to 80 °C

  • Ambient: -25 to 80 °C

  • Storage: -40 to 100 °C

• Durability: > 100 million pressure cycles

• Ingress Protection: IP65

• Shock Resistance: 50 g (DIN IEC 68-2-27)

• Vibration Resistance: 20 g (10–2000 Hz)

Smart Functionality via IO-Link:

• Hysteresis/window mode

• Switch-on/switch-off delay

• Switching logic and diagnostics

• Damping configuration

• Pressure unit selection

• Two programmable switching outputs

Engineered for long-term use, fast response, and seamless integration, this pressure sensor is ideal for automation systems in hydraulic, pneumatic, water treatment, and manufacturing processes.
Upgrade your industrial sensing solution today.
