PN7060 IFM Pressure Sensor

Digital Pressure Sensor – 0...600 bar | IO-Link Compatible | G 1/4 Connection

Reliable, high-performance pressure monitoring for industrial applications.

This digital pressure sensor is engineered for precision and durability in demanding environments. With a broad measuring range of 0...600 bar (0...8700 psi / 0...60 MPa), it is ideally suited for monitoring liquids and gases in industrial systems.

Key Features:

• Measurement Range: 0...600 bar / 0...8700 psi / 0...60 MPa

• Output: 2 programmable digital outputs (PNP/NPN), configurable as normally open or normally closed

• Process Connection: G 1/4 internal thread

• Display: 4-digit red/green LED with selectable units (bar, psi, MPa)

• IO-Link Communication: Supports COM2, IO-Link v1.1 for advanced data transfer and diagnostics

• Switching Points:

  • SP1 = 150 bar, rP1 = 138 bar

  • SP2 = 450 bar, rP2 = 438 bar (factory settings)

• Repeatability & Accuracy:

  • Switching accuracy: < ±0.5% of span

  • Repeatability: < ±0.1%

  • Long-term stability: < ±0.05% per 6 months

Durability You Can Trust:

• Overload & Burst Pressure Ratings:

  • Rated: 800 bar (11600 psi)

  • Burst: 1200 bar (17400 psi)

• Environmental Protection: IP67-rated housing for reliable performance in harsh industrial conditions

• Robust Construction: Stainless steel body (630/1.4542) with gold-plated electrical contacts

Electrical & Functional Specifications:

• Operating Voltage: 18–36 V DC

• Current Consumption: < 35 mA

• Protection: Reverse polarity, overvoltage (< 40 V), and short-circuit protection (pulsed)

• Response Time: < 3 ms

• Switching Frequency: < 170 Hz

• Temperature Range:

  • Medium: -25 to 80 °C

  • Ambient: -20 to 80 °C

  • Storage: -40 to 100 °C

Smart Software Functions:

• Hysteresis/window mode

• Switch-on/switch-off delay

• Diagnostic functions

• Damping configuration

• IO-Link process and diagnostic data access

Compliance & Approvals:

• EMC Standards: EN 61000-4-2/3/4/5/6

• Shock/Vibration Resistance: 50 g / 20 g

• MTTF: 219 years

• UL Certified

Ideal for integration in hydraulic and pneumatic systems, this sensor provides accurate pressure feedback and remote configurability for seamless automation and diagnostics.

Optimize your process efficiency and safety—add this digital pressure sensor to your industrial toolkit today.
