PN7070 IFM Pressure Sensor | Industrial Pressure Sensor – KMSPARE

High-Performance Pressure Sensor | 0–400 bar | IO-Link Interface | G 1/4 Threaded Connection

Ensure precision and reliability in demanding industrial applications with this robust pressure sensor, engineered to monitor pressures up to 400 bar (5800 psi / 40 MPa). Designed with a metallic thin film measuring cell, this sensor offers excellent durability and long-term stability — ideal for both liquids and gases in industrial environments.

🔧 Key Features:

• Measuring Range: 0...400 bar | 0...5800 psi | 0...40 MPa

• Process Connection: G 1/4 internal thread (rotatable for optimal alignment)

• Digital Outputs: 2 (PNP/NPN, NO/NC configurable)

• Output Signal: Switching signal + IO-Link (COM2, 38.4 kBaud)

• Display: 4-digit red/green alphanumeric + 5 LED indicators (green/yellow)

• Housing: Rugged stainless steel (630/316L), IP65/IP67 protection class

⚙️ Advanced Capabilities:

• Gold-plated contacts for corrosion-resistant performance

• Switch point accuracy: ±0.5% of span | Repeatability: ±0.1%

• Response time: < 3 ms | Switching frequency: < 170 Hz

• Programmable functions: hysteresis/window, delay, damping, switch logic, and more

• Min. pressure cycles: 100 million for long-term operation

• Ambient Temperature Range: -25°C to +80°C

📡 IO-Link Smart Sensor:

• IO-Link revision 1.1 compliant (IEC 61131-9)

• Supports both cyclical and acyclical data

• Resolution: up to 0.2 bar / 0.02 MPa

• Enables remote configuration, diagnostics, and process transparency

✅ Certifications & Approvals:

• EMC: DIN EN 61000-6-2 / 6-3

• Shock Resistance: 50 g (11 ms)

• Vibration Resistance: 20 g (10–2000 Hz)

• UL Listed (UL J003)

• PED Compliant: Group 2 fluids (Group 1 on request)

📦 Specifications Summary:

• Operating Voltage: 18–30 V DC

• Current Consumption: < 35 mA

• Overload Protection & Reverse Polarity Protection

• Vacuum Resistance: -1000 mbar

• MTTF: 214 years

• Weight: 240 g

• Connection: M12, gold-plated contacts

Perfect for integration in hydraulic, pneumatic, and process automation systems.
This sensor combines accuracy, flexibility, and ruggedness for superior pressure control in harsh industrial environments.
