PN7092 IFM Pressure Sensor | Industrial Pressure Sensor – KMSPARE

• •

  • Vacuum resistance: -1000 mbar (-0.1 MPa)

• Industrial Durability:

  • Ambient temperature: -25°C to 80°C

  • Storage temperature: -40°C to 100°C

  • IP65 / IP67 protection rating

  • Shock resistance: 50 g (11 ms)

  • Vibration resistance: 20 g (10–2000 Hz)

  • Designed for 100 million+ pressure cycles

• User Interface & Configuration:

  • 4-digit red/green alphanumeric display

  • 3 LED indicators (pressure units: bar, psi, MPa)

  • 2 yellow LEDs for switching status

  • Configurable logic, hysteresis/window mode, delays, and units

  • Rotatable G 1/4 process connection for flexible installation

• Electrical & Mechanical Specs:

  • Operating voltage: 18–30 V DC

  • Current consumption: < 35 mA

  • Connector: M12 (gold-plated contacts)

  • Short-circuit, overload, and reverse polarity protection

  • Housing: Stainless steel (316L), PBT-GF20

  • Wetted parts: Stainless steel (316L), ceramic, FKM

  • Dimensions: Ø 34 mm x L 90.7 mm

  • Weight: 272 g

  • Recommended tightening torque: 25–35 Nm

Applications:

• Hydraulic and pneumatic systems

• Industrial automation and high-pressure machinery

• Liquid pressure monitoring in harsh environments

• OEM solutions requiring robust sensing with digital communication

Model Number: PN7002
Pack Quantity: 1 Unit
Compliance: CE, EMC, UL Certified, PED Compliant
MTTF (Mean Time To Failure): 260 years

💡 Why Choose the PN7002?
For applications demanding high-pressure resilience, accuracy, and smart connectivity, the PN7002 stands out with IO-Link functionality, LED diagnostics, and a robust stainless steel design. A dependable choice for mission-critical industrial operations.
