PN7093 IFM Pressure Sensor

PN7003 High-Performance Pressure Sensor with IO-Link | 0–25 bar

Rugged, Precise & IO-Link Enabled Pressure Monitoring for Demanding Applications

Built to perform in tough industrial conditions, the PN7003 pressure sensor offers high-precision pressure measurement with robust construction and intelligent communication. Designed for monitoring liquids and gases, this sensor features a ceramic-capacitive sensing element and IO-Link connectivity for real-time diagnostics and streamlined integration.

Key Features:

• Measuring Range:

  • 0…25 bar | 0…362 psi | 0…2.5 MPa

  • Pressure Type: Relative pressure (supports vacuum detection)

  • Conditionally suitable for gaseous media (up to 25 bar)

• Output & Configuration:

  • 2 Digital Outputs (configurable PNP/NPN)

  • IO-Link Communication (COM2, Revision 1.1)

  • Switch output logic: Normally Open / Normally Closed (parameterisable)

• Superior Accuracy & Responsiveness:

  • Switch point accuracy: < ±0.5% of span

  • Repeatability: < ±0.1%

  • Long-term stability: < ±0.05% (per 6 months)

  • Response time: < 3 ms

  • IO-Link resolution: Up to 0.01 bar / 0.001 MPa

• Reliable in Harsh Conditions:

  • Operating temperature: -25 to 80°C

  • Storage temperature: -40 to 100°C

  • Shock resistance: 50 g (11 ms), Vibration: 20 g (10–2000 Hz)

  • High-pressure resilience:

    • Pressure Rating: 150 bar (2175 psi)

    • Burst Pressure: 350 bar (5075 psi)

• User-Friendly Display & Setup:

  • 4-digit alphanumeric red/green display

  • LED indicators for unit (bar, psi, MPa) & switching status

  • Configurable switching logic, hysteresis/window, damping, display units

  • Rotatable G 1/4 internal thread process connection for easy alignment

• Robust Mechanical Design:

  • Housing: Stainless steel (316L), PBT-GF20

  • Wetted parts: 316L stainless steel, ceramics, FKM

  • Protection class: IP65 / IP67

  • Lifetime: ≥ 100 million pressure cycles

  • Weight: 235 g | Dimensions: Ø 34 mm x L 90.7 mm

Electrical & Interface Specs:

• Voltage Supply: 18–30 V DC (SELV/PELV compliant)

• Current Consumption: < 35 mA

• Short-circuit, reverse polarity, and overload protection

• Connector: M12, A-coded with gold-plated contacts

• Power-on delay: < 0.3 s

• IO-Link cycle time: Min. 2.3 ms

• Profile support: Smart Sensor SSP 0 / 3.1

Ideal For:

• Hydraulic & pneumatic systems

• Industrial automation and OEM machinery

• Monitoring pressurized liquid or gas media

• Systems requiring stable long-term sensing in demanding environments

Model Number: PN7003
Pack Quantity: 1 unit
Compliance: CE, UL, EMC-tested, Pressure Equipment Directive
MTTF: 260 years

💡 Why Choose the PN7003?
Delivering industry-grade pressure sensing with intuitive IO-Link integration and a rugged build, the PN7003 is your go-to sensor for reliability, configurability, and long-term performance under pressure.
