PN7570 IFM Pressure Sensor

IFM PN7000 Pressure Sensor | 0–400 bar | IO-Link Compatible

Ensure precision and reliability in demanding industrial applications with the IFM PN7000 Pressure Sensor. Designed for monitoring relative pressure in liquids and gases, this sensor offers high performance with an impressive pressure range of 0 to 400 bar (0–5800 psi / 0–40 MPa) and robust protection against overpressure and vacuum.

Key Features:

• Wide Pressure Range:
  Measures up to 400 bar, ideal for high-pressure industrial systems.

• Exceptional Durability:
  Withstands burst pressure up to 1700 bar and vacuum resistance to -1000 mbar, offering long-term stability over 100 million pressure cycles.

• Advanced Output Options:
  Dual digital outputs with PNP/NPN configuration, plus IO-Link communication for easy integration and parameterization.

• High Accuracy & Repeatability:

  • Switch point accuracy: ±0.5%

  • Repeatability: ±0.1%

  • Long-term stability: ±0.05% (per 6 months)

• Fast Response Time:
  Less than 3 ms, ensuring real-time monitoring and control.

• Robust Build Quality:
  Made with stainless steel (630/316L) for wetted parts and resistant housing materials for harsh environments.

• Clear Visual Feedback:
  Includes 3 green LEDs for pressure units, 2 yellow LEDs for switching status, and a 4-digit red/green alphanumeric display.

• Versatile Process Connection:
  G 1/4 external thread with internal M5 thread.

• Temperature Resistance:
  Operates reliably in temperatures from -25°C to 80°C with storage capability down to -40°C.

• Protection Class:
  Rated IP65 and IP67 for superior dust and water resistance.

Electrical Specifications:

• Voltage: 18–30 V DC

• Current consumption: < 35 mA

• Switching frequency: < 170 Hz

• Short-circuit and overload protection included

• Connector: M12 (gold-plated contacts)

Software & Interface:

• IO-Link Version 1.1 (COM2, 38.4 kBaud)

• Programmable settings: Hysteresis, switching logic, damping, delay times, and more

• IO-Link resolution: 0.2 bar / 0.02 MPa

• Min. process cycle time: 2.3 ms

Applications:
Ideal for industrial automation, hydraulic systems, pneumatic monitoring, and any application requiring precise high-pressure measurement.

Brand: IFM
Model No.: PN7000
Weight: 257.5 g
