PRWL18-8DN Autonics Inductive Proximity Sensor

Autonics PRWL18-8DN Inductive Proximity Sensor | 8mm Sensing | M18 | IP67 Rated

The Autonics PRWL18-8DN is a high-performance inductive proximity sensor designed for reliable object detection in industrial automation systems. With an 8mm sensing distance, M18 diameter, and non-flush installation, this sensor delivers fast response times and excellent durability, even in demanding environments.

Key Features:

• Brand: Autonics

• Model: PRWL18-8DN

• Sensor Type: Inductive Proximity Sensor

• Usage: Industrial applications

• Sensing Distance: 8 mm (non-flush installation)

• Sensing Range: 10 mm

• Standard Target: 25×25×1 mm (iron)

• Body Material: Stainless Steel

• Sensing Side Diameter: M18

• Operating Voltage: 10 – 30 V DC

• Maximum Load Current: 10 mA

• Power Supply Voltage: 30 V max

• Response Frequency: 350 Hz

• Operating Frequency: 3560 Hz

• Operating Temperature: -25°C to +70°C

• Weight: 142 g

• Protection Rating: IP67 equivalent

Applications:

• Factory automation systems

• Position detection on machinery

• Object counting and sensing

• Non-contact metal detection in conveyors and robotics

Why Choose Autonics PRWL18-8DN?
Built with robust stainless steel housing and optimized for non-contact metal sensing, the PRWL18-8DN ensures precise performance and long-term stability in harsh industrial environments.
