PX3980 IFM Pressure Transmitter

IFM PX3980 Pressure Transmitter | 0-150 psi | IP68 Protection

The IFM PX3980 Pressure Transmitter is engineered for reliable and precise pressure monitoring in demanding industrial and mobile applications. Featuring a robust ceramic measuring cell, this transmitter offers high accuracy, long-term stability, and exceptional durability even under harsh conditions.

Key Features:

• Measurement Range: 0–150 psi

• Accuracy: 100%

• Output Type: NPN with precise analog output

• Voltage Range: 9.6 – 32 V (Rated supply voltage: 36 V)

• Response Time: Ultra-fast 2 ms

• Max Load: 720

• Protection Rating: IP68 – ideal for harsh environments

• Housing: Cylindrical design for compact installation

• Dimensions: Diameter 30 mm, Length 79.5 mm

• Weight: 210 g

• Model No.: PX3980 (PA-400-SBR14-A-ZVG/US//V)

Benefits:

• Reliable detection of system pressure

• High overload protection ensures long-term stability

• Designed for over 100 million pressure cycles

• Excellent resistance to shock and vibration

Whether for hydraulic systems, pneumatic control, or other industrial processes, the IFM PX3980 provides a rugged, high-performance solution for pressure measurement needs.
