PZ-34-A-200 Gefran Position Transducer

Transducer Type Displacement Protection IP60 Product Type Linear Displacement Position Transducer Size 200mm Mechanical Stroke 200mm Resistance 8 k ohm Type . Resistive Type Shape Cylinderical F Code F004411 Working Temp -30 to 100 Deg C 25 to 300 mm stroke Mechanical fixing using brackets, selfaligning ball-joints or flange Independent linearity up to ± 0.05% Infinite resolution No variation of electrical signal outside theoretical electrical stroke Displacement speed 10 m/s Working temperature: -30…+100°C Electrical connection: 3-pole screened cable (1m length) Life duration: > 25×106 meters or >100×106 operations, whichever is the smaller (within C.E.U.) Grade of protection IP60
