RA3102 IFM Incremental Encoder

🌀 IFM RA3102 Incremental Encoder | Hollow Shaft | Magnetic Detection | IO-Link | Stainless Steel

Upgrade your industrial automation with the IFM RA3102, a high-performance incremental encoder built for precise motion tracking and rotational speed detection. Designed with a 12 mm hollow shaft, this encoder offers programmable resolution and robust protection features—ideal for high-demand environments.

🔍 Key Features:

• Encoder Type: Incremental, Two-Phase Output

• Resolution: Programmable from 1 to 10,000 (Factory Default: 1024)

• Sensor Principle: Magnetic detection for exceptional shock and vibration resistance

• Communication Interface: IO-Link for seamless data exchange

• Reverse Polarity Protection: Yes

• Shaft Design: Hollow shaft open to one side for easy mounting

• Material: Stainless Steel for industrial durability

⚙️ Technical Specifications:

• Model/Type: RA3102

• Brand: IFM

• Voltage: 12 – 24 V DC (Operating: 4.75 – 30 V DC)

• Nominal Supply Voltage: 24 V

• Frequency: 50 / 60 Hz

• Output Frequency: 50 / 60 Hz

• Max Output Current: 150 mA

• Current Consumption: < 150 mA

• Shaft Diameter: 12 mm

• Product Weight: 256 g

• Protection Class: III

• Color: Silver

• Accuracy: 100%

• Usage/Application: Industrial motion sensing, motor feedback systems

🏭 Applications:

• Motion control and speed monitoring

• Precision position feedback in automation systems

• OEM machinery and factory equipment

• Rugged environments with high vibration

Bring precision and reliability to your automation setup with the IFM RA3102 Encoder—engineered to perform in the most challenging industrial settings.
