RA3103 IFM Incremental Encoder

🔧 IFM RA3103 Incremental Encoder | Hollow Shaft | Magnetic Sensing | Stainless Steel | Industrial-Grade

The IFM RA3103 is a robust incremental encoder designed for precision, durability, and reliable speed detection in industrial environments. With a 10 mm hollow shaft and a freely programmable resolution of up to 10,000 pulses, this encoder delivers high accuracy and consistent performance even in demanding applications.

✅ Key Features:

• Encoder Type: Incremental, Two-Phase Output

• Resolution: Programmable from 1 to 10,000 (Factory Default: 1024)

• Sensor Principle: Magnetic, offering enhanced shock and vibration resistance

• Shaft Design: Hollow shaft for easy integration

• Material: Corrosion-resistant stainless steel housing

• Mounting: Compact and rugged form factor for space-saving installation

📊 Technical Specifications:

• Model/Type: RA3103

• Brand: IFM

• Output Reading: Two Phase

• Operating Voltage: 12 – 24 V DC (Nominal Supply: 12 – 30 V DC)

• Frequency: 50 / 60 Hz

• Output Frequency: 50 Hz

• Max Output Current: 15 mA

• Shaft Diameter: 10 mm

• Material: Stainless Steel

• Color: Silver

• Usage/Application: Industrial automation, motion detection

• Weight: — (refer to datasheet if needed)

🏭 Applications:

• Position and speed detection

• Motor and conveyor monitoring

• Automated production lines

• Environments with high vibration or temperature variations

Get reliable rotational feedback and precise linear measurements with the IFM RA3103 Incremental Encoder — engineered to deliver performance where it matters most.
