🌀 IFM RA3104 Incremental Encoder | Hollow Shaft | IO-Link | Magnetic Detection | Stainless Steel

The IFM RA3104 is a high-performance incremental encoder built for reliable industrial motion control. Featuring a 6 mm hollow shaft and IO-Link communication, it delivers precise feedback with programmable resolution and advanced diagnostics. Ideal for systems requiring compact, robust, and efficient sensing technology.

🔍 Key Features:

• Encoder Type: Incremental (Two-Phase Output)

• Resolution: Programmable from 1 to 10,000 pulses (Factory setting: 1024)

• Communication: IO-Link enabled for advanced monitoring and integration

• Detection System: Magnetic, offering high shock and vibration resistance

• Shaft Design: Hollow shaft open to one side for easy mounting in tight spaces

• Robust Material: Stainless steel housing ensures long-lasting durability

⚙️ Technical Specifications:

• Model: RA3104

• Brand: IFM

• Voltage Range: 12 – 30 V DC (Operating voltage: 4.75 – 30 V DC)

• Output Frequency: 50 / 60 Hz

• Output Reading: Two Phase

• Current Consumption: < 150 mA

• Maximum Output Current: 35 mA

• Shaft Diameter: 6 mm

• Frequency: 60 Hz

• Protection Class: III

• Reverse Polarity Protection: Yes

• Material: Stainless Steel

• Color: Silver

• Weight: 266 g

• Mounting Type: Hollow shaft (open end)

🏭 Ideal For:

• Industrial automation systems

• Rotational speed and position feedback

• Applications requiring magnetic resistance and IO-Link diagnostics

Experience durability, accuracy, and seamless integration with the IFM RA3104 Incremental Encoder — a compact powerhouse for your automation needs.
