RA3501 IFM Incremental Encoder

🌀 IFM RA3501 Incremental Encoder | Hollow Shaft | Magnetic Sensing | Industrial-Grade

The IFM RA3501 Incremental Encoder is built for reliable performance in industrial automation systems. With a hollow shaft design and magnetic sensing principle, this encoder is ideal for high-precision rotational speed and position feedback, even in harsh operating environments.

🔧 Key Features:

• Encoder Type: Incremental, Two-Phase Output

• Shaft Design: Hollow shaft for direct shaft mounting

• Resolution: Freely programmable from 1 to 10,000 pulses (factory setting: 1024)

• Sensing Principle: Magnetic – shock and vibration-resistant

• Defined Pulse Sequence: Ensures precise rotational speed and position detection

• Compact & Robust: Stainless steel housing with IP-grade durability

📊 Technical Specifications:

• Model Number: RA3501

• Brand: IFM

• Material: Stainless Steel

• Voltage Range: 12 – 30 V DC

• Residual Propagation: 4.75 – 30 V

• Max. Output Current: 15 mA

• Max. Rotation Speed: 30 mA

• Frequency: 60 Hz

• Output Reading: Two Phase

• Weight: 318 g

• Shaft Diameter: 10 mm (hollow shaft)

• Operating Temperature: -40°C to +80°C

• Color: Silver

• Application: Industrial machinery, automation, robotics

✅ Ideal For:

• Rotary motion control

• Industrial automation systems

• Environments requiring high durability and precision

Ensure maximum performance and reliability in your systems with the RA3501 Incremental Encoder — the dependable solution for industrial-grade motion detection.
