RL61-LL-IR-Z-92-136 P&F Photoelectric Sensor

🔍 P&F RL61-LL-IR-Z/92/136 Photoelectric Sensor | Infrared Light | 500 mm Range | Background Suppression

The Pepperl+Fuchs RL61-LL-IR-Z/92/136 is a high-precision photoelectric sensor designed for reliable object detection with background suppression. Featuring a modulated infrared light source and adjustable sensing range up to 500 mm, this compact sensor ensures accurate performance in a wide range of industrial environments.

⚙️ Key Features:

• 🌫️ Detection Range: Adjustable from 200 to 500 mm

• 🔦 Modulated Infrared Light (850 nm) for precise detection with minimal interference

• 🎯 Light Spot Diameter: Approx. 6 mm at 500 mm distance

• 🌓 Light/Dark Switch with time delay adjustment (0–50 ms)

• 🧠 Background Suppression up to +10% of upper detection range

• 📊 Indicators:

  • Green LED: Power & Operation

  • Yellow LED: Target Detection Status

• 💡 Black/White Difference <8% at 500 mm for stable sensing performance

📐 Technical Specifications:

• Model No.: RL61-LL-IR-Z/92/136

• Brand: Pepperl+Fuchs (P&F)

• Material: ABS

• Accuracy: 100%

• Supply Voltage: 10–30 V DC

• Switching Voltage: 30 V

• Activation Current: 15 mA

• Detection Range: 20–500 mm

• Adjustment Range: 200–500 mm

• Light Source: IRED (Infrared Emitting Diode)

• Light Type: Modulated Infrared Light, 850 nm

• Ambient Light Limit: 30,000 Lux

• Angle of Divergence: 0.7°

• Operating Temperature: -20°C to +75°C

• Weight: 120 g

• Active Area: 15 mm

✅ Ideal For:

• Industrial automation and material handling

• Applications requiring precise target detection and ambient light immunity

• Installations with variable object reflectivity or distance

Experience consistent and reliable sensing with the P&F RL61-LL-IR-Z/92/136 Photoelectric Sensor — optimized for challenging environments and precise results.
