S15-PA-3-B00-PK Datalogic Photoelectric Sensor

Datalogic S15-PA-3-B00-PK Photoelectric Sensor – Compact, Rugged, IP69K Rated

The Datalogic S15-PA-3-B00-PK is a durable and high-performance photoelectric sensor engineered for demanding industrial environments. Built with a compact form factor and tough PBT housing, this sensor is ideal for precise object detection in space-constrained applications. Its IP65, IP67, and IP69K protection makes it suitable even for washdown and harsh-duty operations.

Operating on 12–30 VDC, it offers stable and reliable output with low power consumption (≤ 25 mA) and up to 100 mA output current. Designed for maximum electrical protection and environmental resistance, this sensor includes essential features like ambient light rejection, shock/vibration resistance, and dual housing options (ABS or stainless steel).

Key Features:

• Model: S15-PA-3-B00-PK

• Brand: Datalogic

• Sensor Type: Photoelectric Sensor

• Material: PBT (Optional housing in ABS TERLURAN or INOX AISI 316L)

• Accuracy: 100%

• Active Area: 8 mm

• Operating Temperature: -25°C to +70°C

• Color: Black

• Weight: 40 g

• Power Supply: 12–30 VDC

• Ripple: ≤ 2 Vpp

• Current Consumption: ≤ 25 mA

• Output Current: ≤ 100 mA

• Saturation Voltage: ≤ 2 V

• Dielectric Strength: 500 VAC for 1 minute (electronics to housing)

• Insulation Resistance: > 20 MΩ at 500 VDC

• Mechanical Protection: IP65 / IP67 / IP69K

• Ambient Light Rejection: EN 60947-5-2 compliant

• Vibration Resistance: 0.5 mm amplitude, 10–55 Hz (EN60068-2-6)

• Protection Devices: A, B²

• Indicators:

  • Yellow OUTPUT LED

  • Green STABILITY LED

  • Green POWER LED (on emitter models)

Applications:
Ideal for industrial automation, packaging, food processing, and material handling systems requiring compact sensors with high environmental resistance and reliable detection performance.
