S15-PA-5-C11-PK Datalogic Photoelectric Sensor

Datalogic S15-PA-5-C11-PK Photoelectric Sensor – Compact, Durable, IP69K Rated

The Datalogic S15-PA-5-C11-PK is a compact and rugged photoelectric sensor built for high-performance object detection in industrial environments. With a robust PBT housing, versatile cable or M12 connection options, and IP65, IP67, and IP69K protection ratings, this sensor is ideal for washdown and harsh-duty applications.

Operating on 12–30 VDC and supporting up to 100 mA output current, this sensor ensures reliable and stable detection. It also features ambient light rejection, selectable light/dark operating mode, and multiple status indicators (OUTPUT, STABILITY, and POWER LEDs) for user-friendly setup and diagnostics.

Key Features:

• Model: S15-PA-5-C11-PK

• Brand: Datalogic

• Sensor Type: Photoelectric Sensor

• Material: PBT (with optional metal housing in INOX AISI 316L)

• Accuracy: 100%

• Active Area: 10 mm

• Voltage Range: 12–30 VDC

• Ripple: ≤ 2 Vpp

• Current Consumption: ≤ 25 mA

• Output Current: ≤ 100 mA

• Saturation Voltage: ≤ 2 V

• Dielectric Strength: 500 VAC for 1 min

• Insulation Resistance: > 20 MΩ at 500 VDC

• Mechanical Protection: IP65 / IP67 / IP69K

• Ambient Light Rejection: According to EN 60947-5-2

• Vibration Resistance: 0.5 mm amplitude, 10–55 Hz (per EN60068-2-6)

• Protection Devices: A, B²

• Color: Black

• Weight: 35 g

• Connection Options:

  • 2 m Cable (PVC, 4 x 0.14 mm²)

  • M12 4-pole connector

  • Pig-tail (150 mm cable + M12 connector)

• Indicators:

  • Yellow OUTPUT LED

  • Green STABILITY LED

  • Green POWER LED (for through beam emitters)

• Operating Modes: Selectable Light/Dark

• Auxiliary Functions: Test+ and Test- inputs (Emitter off control)

Applications:
Perfect for use in automated production lines, washdown zones, food & beverage processing, packaging systems, and other industrial automation setups requiring compact, high-durability sensors.
