S18M-5-C-30 Datalogic Photoelectric Sensor

Datalogic S18M-5-C-30 Photoelectric Sensor – Infrared/Red Light, PNP/NPN Selectable Output, 8mm Active Area

The Datalogic S18M-5-C-30 is a high-performance photoelectric sensor designed for precision object detection in industrial environments. With a compact cylindrical form factor, durable PBT housing, and selectable NPN/PNP output, it offers versatility and reliability for automated systems.

This sensor features both infrared (880 nm) and red light (660 nm) emission, a fast response time of 1–2 ms, and a wide operating distance—making it suitable for a broad range of detection tasks. Equipped with short-circuit protection, LED indicators, and sensitivity trimmer (on specific models), it’s designed for easy setup and robust operation.

Key Features:

• Model: S18M-5-C-30

• Brand: Datalogic

• Sensor Type: Photoelectric Sensor

• Material: PBT

• Accuracy: 100%

• Active Area: 8 mm

• Operating Temperature: -25°C to +55°C

• Storage Temperature: -25°C to +70°C

• Voltage Range: 10–30 VDC

• Current Consumption: 30 mA max. (excluding output current)

• Output Type: NPN/PNP Selectable (4-wire version)

• Output Current: 150 mA max.

• Output Saturation Voltage: 2.5 V max. (4-wire) / 1.8 V max. (3-wire)

• Output Leakage: 50 µA @ 30 VDC

• Switching Frequency: Up to 500 Hz

• Response Time: 1–2 ms max.

• Indicators:

  • Power ON: Green LED

  • Output: Yellow LED

• Operating Distance:

  • C Model: 1–30 cm

  • K Model: 1–10 cm

  • F/G Model: 0–12 m

• Emission Type: Infrared (880 nm) / Red (660 nm)

• Protection: Short-circuit protection, Electric shock class 1 (S18M version)

• Weight: 58 g

Applications:
Ideal for industrial automation, conveyor systems, packaging machinery, and positioning systems where fast and accurate object detection is required.
